Machinery
Foam Production Line
Continuous slabstock lines for flexible polyurethane foam production.
Foam Production Line — Machine specification
| Property | Typical value | Unit |
|---|---|---|
| Line type | Continuous horizontal slabstock | |
| Block width | 1,200–2,200 | mm |
| Block height | ≤ 1,300 | mm |
| Output rate | 60–200 | kg/min |
| Conveyor length | 25–40 | m |
| Metering streams | Polyol, isocyanate, water, catalysts, silicone surfactant and auxiliary blowing agent | |
| Block cutting | Programmable transverse cutter | |
| Control system | PLC with touchscreen HMI |
Machine specifications are configurable. Working width, capacity and line configuration are built to order — the figures shown indicate the typical range available.
Available configurations
- Continuous slabstock foaming
- Box foaming — discontinuous
- Horizontal and vertical block cutting
Scope of supply
Supplied as a complete line: mechanical equipment, electrical control cabinets, installation drawings, commissioning supervision and operator training. Scope is agreed in writing before order confirmation.
Foam Production Line — Applications
- Furniture cushioning
- Mattress and bedding foam
- Protective packaging foam
- Automotive seating
Industries served
Documentation
Technical and safety documentation is issued on request, and always before order confirmation.
Technical Data Sheet (TDS)
Full specification and typical properties
Safety Data Sheet (SDS)
Handling, transport and hazard information
Certificate of Analysis (COA)
Issued per production batch on shipment
